Description
- 10.1″ 1024 x 600 Resolution with Projected Capacitive Multi-Touch (P-CAP)screen
- Fanless cooling system and ultra low power consumption
- Edge-to-edge design
- Special M12 Waterproof connectors
- Full IP6
- 1 x LAN, 1 x RS232, 1 x USB
RBT W10IB3S-MSH1(HB)
»Intel Core i7/i5/i3/Pentium/celeronLGA1155/1150/775-Socket Motherboard,
»Resistive 5 Wire Touch Screen,
»IP64/65/66Grade Front Bezel,
»I/O:DVI/VGA/2*LAN/5*USB/4*COM/AUDIO/PCIex4/Wifi
Hardware Specification
| SPEC ITEM | DESCRIPTION |
| LCD Panel Specification | |
| Size | 10.1″ TFT (Widescreen) |
| Active Display Area | 222.72(H) x 125.2/(V) |
| Resolution | 1024 x 600 |
| Contrast Ratio | 800:01:00 |
| Display Color | 16.7M |
| Brightness | 450cd/m2(typ.) |
| Viewing Angle | -75~80(H);-80~80(V) |
| Touch Screen | Projected Capacitive Multi-Touch (P-CAP)with optional for protection glass |
| System Specification | |
| Processor | Intel® Celeron® Bay Trail-M N2930 1.83GHz |
| Chipset | Intel® ATOM SoC Integrated |
| Memory | 2GB DDR3L 1600 SODIMM (max. 8 GB) |
| Serial | 1 x RS232/422/485 |
| Storage | 64GB mSATA SSD |
| OS | Windows 10 IoT Enterprise |
| Windows Embedded 8.1 Industry Pro | |
| Windows Embedded Standard 7 | |
| Security Support | Trusted Platform Module (TPM1.2) |
| LAN | Dual Intel® WG82574L GbE LAN |
| Waterproof IP65 Grade Connectors | |
| USB Port | 1 x USB 2.0 (M12 Type) |
| Ethernet | 1 x 10/100/1000 LAN (M12 Type) |
| COM Port | 1 x RS232 (M12 Type)(Optional 422/485) |
| I/O Connectors | |
| Speaker | 1 x 1 Watt Speaker |
| Mechanical and Environment | |
| Operating Temperature | -10°C to 55°C |
| Operating Humidity | 10% to 95% (non-condensing) |
| Cooling System | Fanless design |
| Dimension (W x H x D) | 263.28 x 172 x 35.7 (mm) |
| IP Proof | Full IP65 |
| Shock | Operating: 30g for 18ms, 300m/s² |
| Mouting | VESA Mount(75 x 75 mm), Panel Mount |
| Vibration | Operating: 1.60/1.96/2.18 g rms for XYZ / 5-500Hz |
| Power | |
| Power Input | 9-36V DC (M12 type) |
| Power Consumption | 10W |
| Software | |
| Utility | Watchdog SDK |
