Description
| SPEC ITEM | DESCRIPTION |
| Size | |
| General Size | 5.2″ to 22″ |
| Custom Size | 2.2″ to 22″ |
| Fit in with | Panel display device |
| Performance | |
| Resolution(Interpolation) | 4096*4096 |
| Linearity Error | <1.5% |
| Response Speed | <10ms |
| Mechanical | |
| Input Method | Finger or gloved hand (rubber ,cloth or leather) |
| Touch Times | More than 1 million touches |
| Touch Activation Force | 15~70g |
| Surface Durability | Meets pencil hardness 3H (per ASTM D3363) |
| Optical | |
| Light Transmission | 80%（Meet ASTM D1003） |
| Environmental | |
| Temperature | Operating Range: -10°C ~ 60°C |
| Relative Humidity | Operating Range: 0%~90% RH (no dew falls) |
| Storage Range: 0% to 95% RH (no dew falls) | |
| Altitude | Up to 3,000m |
| Electrical | |
| Operation Voltage | Typical +DC 5V, +4.75V to +5.25V |
| Power Supply | USB or PS/2 Interface |
| Interface | Full Duplex USB 2.0 (Full Speed) Plug and play compatible |
| Serial RS-232. Baud Rate: 9600, 8 Data Bits, 1 Stop Bit, No Parity | |
| Current | 5mA~25mA |
| Electrostatic Endurance | No abnormal appearance after 10kv, 100Ω, 250PF electrostatic used |
| Isolation Resistance | >20MΩ @ DC 25V |
| Resistance | 300Ω< X Axis <900Ω, 200Ω< Y Axis <800Ω (Varies with different size) |
