Description
| SPEC ITEM | DESCRIPTION |
| Dimension (W*H*D) | 19“*7”*20.87“/ 482*177*530mm |
| Material Construction | Heavy-duty High-end cold-rolled steel Thickness:1.0 |
| M/B Size | EEB (12″X13″) or Industrial passive backplane |
| Expansion | 7 slots rear side ATX or 14slot |
| Control & Indicator | 1*Power switch +1* Reset switch |
| 1 x LED (power) +1 x LED (HDD), 1 x LED (KB-LK) | |
| 2*2.0 USB | |
| Cooling Fans | 1*12cm Fan in front+1*6cm in middle+2*8cm on topcover |
| DriveBay | 2 x 5.25“ + 1 x 3.5” (external) + 8 x 3.5“ (internal) |
| Power Supply | Standard PS-2 ATX or PS-2 size Mini-Redundant |
| Power supply 300w~500w | |
| Sliding rail | 20″ball bearing sliding rail(option) |
| Color | Black or Beige |
| Operation Temperature | Up to 50C (122℉) |
| Operation Humidity (Non-condensing) | Up to 90% |
| Packing Measurement CBF / CBM | 3.0 / 0.085 |
| Packing N.W / G.W | 12.0KGS /14.0KGS |
