Description
| SPEC ITEM | DESCRIPTION |
| Induction method | The improved projected sensing technology, criss-cross X, Y nanowires constitute sensing matrix |
| Touch size | 17″~94″(4:3) or 17″~120″(16:9) can be customized |
| Paste way | Removable Imperial or permanent paste |
| Touch accuracy | No drift, the deviation is about 1~3mm |
| Calibration way | software calibration |
| The number of wires | Nano-wires 40 Road / Road 64/128 |
| Induction thickness (penetration) | Adjusted by software to adapt to various thickness of glass, even wear gloves to produce touch-sensitive, can penetrate non-metallic materials about the thickness of 20 mm (middle to allow air layer), the induction can even penetrate glass thickness aboutof 25mm |
| Scanning frequency | 60Hz~130hz |
| Output way | USB 2.0 (HID public interface to USB Mini B interface) |
| Compatibility | WIN2000/WINXP/WIN7/WIN8/Linux/Mac/android4.0 etc. |
| Touch functionality | Mouse function, multi-point (2) touch support TUIO and Windows Native |
| Temperature range | -20°C~60°C |
| Humidity range | 0% RH to 95% RH (without condensation neighborhood) |
| Transmittance | ＞93% |
| Power consumption | Max 0.5W |
| Product Certification | CE,FCC,ROHS |
| EMC | EN61000-6-1：2007 EN61000-6-3：2007+A1：2011 |
