Description
| SPEC ITEM | DESCRIPTION |
| General | |
| 1 x External Li-Ion battery | System |
| 1 x Intel® 82801DB I/O Controller Hub (ICH4) | Display |
| 2 x RJ45 with LED connector | System |
| 4 Mbit fl ash ROM | System |
| 5 Vsb: 0.5 A | System |
| 64 MB of VGA system memory | Display |
| BIOS | Award System BIOS |
| Certifications | CE approval |
| Chipset | Intel® 845GV |
| Display Interface | Intel 82845GV chipset integrated VGA controller |
| Ethernet | 2 x Intel® 82551QM 10/100 Fast Ethernet controllers for PEAK 715VL2-HT |
| FCC Class A | System |
| I/O | Built-in ITE 8712F-A Super I/O chipset |
| Operating Temperature | Operating temperature: 0°C to 60°C |
| Power Consumption | Power supply maximum consumed power on SBC: |
| Relative humidity: 10% to 90% (Non-condensing) | System |
| RTC | On-chip RTC with battery back up |
| Video: 1 x 15-pin | I/O |
| System | |
| CPU | Socket 478 for Intel® Pentium® 4 / Celeron® processor up to 3.06 GHz and greater with 400/533 MHz FSB. Socket 478 for Intel® Pentium® 4 / Celeron® processor up to 3.06 GHz and greater with 400/533 MHz FSB. Supports Intel® Pentium® 4-M processor up to 2.4 GHz and greater with 400 MHz FSB |
| Dimensions | 338.58 mm (L) x 122 mm (W) (13.3” x 4.8”) |
| Memory | 2 x 184-pin DIMM, up to 2 GB Unbuffered Non-ECC DDR 200/266/333 SDRAM memory |
| Watchdog Timer | Programmable Watchdog timer from 1 ~ 128 seconds |
