SPEC ITEM
| DESCRIPTION |
| System |
| Processor | Intel® Celeron® J1900 Processor (4C @ 2.00 GHz CPU, 688/854 MHz GFX, 10W TDP) |
| Intel® Celeron® N2807 Processor (2C @ 1.58 GHz CPU, 313/750 MHz GFX, 4.3W TDP) |
| Chipset | — |
| Memory | DDR3L 1333 MHz SODIMM x 2 up to 8 GB (for J1900), DDR3L 1333 MHz |
| SODIMM x 1 up to 4 GB (for N2807), Non-ECC, un-buffered memory, Dual- channel memory architecture flat type |
| Graphics | Intel® HD Graphics |
| I/O Chipset | Fintech 81866D |
| Ethernet | Realtek PCIe Gb LAN 8111G x 1 |
| Audio | Realtek® ALC887 (colay ALC892/886) |
| TPM | Infineon SLB9635 TT 1.2 (default : No) |
| Expansion Slot | Full-size Mini-Card (mSATA default) (PCIe+USB optional) + SIM Card (default: No) x 1, Half-size Mini-Card (PCIe+USB) x 1 |
| BIOS | 64 M bit Flash ROM, AMI BIOS |
| H/W Monitor | Temperature Monitor on CPU/System, Voltage Monitor on Vcore/5V/3.3V/12V, Fan Monitor on CPU/Chassis |
| Watchdog Timer | 1~255 steps by software program |
| Smart Fan Control | Chassis Fan (fanless) |
| Wake On LAN/ PXE | Yes (WOL/PXE) |
| Power State | S3, S4, S5 |
| Graphics |
| Graphics Chipset | Intel® HD Graphics |
| Graphics Multi Display | VGA+LVDS, VGA+HDMI, LVDS+HDMI |
| VGA | Up to 1920 x 1200 @60 Hz |
| DVI | — |
| HDMI | Up to 1920 x 1200 @60 Hz |
| DisplayPort | — |
| LVDS | Up to 1920 x 1080 @60Hz, Dual Channel 18/24-bit (via CH7511) |
| eDP | — |
| Backlight Control | Voltage/PWM |
| Environmental & power |
| Battery | Lithium battery |
| Power Requirement | 12VDC |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40°F ~185°F (-40°C ~85°C) |
| Operating Humidity | 0% ~ 90% R/H, non-condensing |
| Certification | CE & FCC |
| Form Factor | Mini-ITX: 6.7” x 6.7” (170mm x 170mm) |
| Weight | 1.1 lb (0.5 Kg) |
| MTBF (hours) | 295750 |
| Rear I/O ports |
| USB | USB 3.0/2.0 x 1, USB 2.0 x 2 |
| Display I/O | HDMI x 1 |
| Audio I/O | Line in x 1, Line-out x 1 |
| LAN I/O | LAN (RJ-45) port x 1 |
| Serial Port | COM (RS-232) x 1 |
| PS/2 Port | — |
| Others | DC port (12V) Screw type x 1 |
| Internal I/O connectors |
| Storage | SATA3 (6.0Gb/s) x 2, SATA2 (3.0Gb/s) x 2 (1 colay with mSATA), SATA power connector x 1, Ful Size Mini-Card slot (mSATA) x 1 |
| USB | USB 2.0 (2 x 5-pin, 2.54mm) x 2 ports support additional 4 USB, USB 2.0 (1x 5-pin, 2.0mm) x 1 port supports additional 1 USB |
| Display I/O | VGA pin header x 1, LVDS connector x 1, LVDS 3V /5V jumper x 1, LCD DC / PWM mode jumper x 1, LCD backlight connector (inverter) x 1, LCD backlight 12V /5V jumper x 1 |
| Audio I/O | AAFP x 1 |
| Serial Port | Boxer header for COM (RS-232) x 4, Boxer header for COM (RS-232/422/485) x 1 |
| PS/2 Port | PS/2 Keyboard Mouse 6 PIN Connector x 1 |
| Parallel Port | SPP/EPP Mode |
| DIO | DIO (4in/4out) x 1 |
| Fan | Chassis Fan connector x 1 |
| Power | 12V AUX Power Connector x 1, AT/ATX mode select jumper (default : No) x 1 |
| Others | Half-size Mini-Card (PCIe + USB) x 1, SIM Card Socket(default : No) x 1, LPT PIN header x 1, Front Panel connector x 1, CMOS jumper x 1 |
| OS |
| OS support | Windows® 10 64-bit |
| Windows® 7 32/64-bit |
| Windows® 8.1 32/64-bit |
| Linux Fedora |
