| SPEC ITEM | DESCRIPTION |
| System |
| Processor | Socket LGA1155 2nd generation Intel® Processor |
| Chipset | Intel® Q67 |
| Memory | Dual-Channel with 240-pin DRAM x 4, DDR3 1333/1066, up to 32GB |
| Graphics | Intel® Graphics |
| I/O Chipset | Winbond W83627DHG |
| Ethernet | Intel® 82579LM / 82574L, Gigabit LAN x 2 |
| Audio | Realtek® ALC662 |
| TPM | Infineon SLB9635TT 1.2(Optional) |
| Expansion Slot | PCIe [x16] x 1, PCIe [x4] x 1, PCIe [x1] x 1, PCI x 4 |
| BIOS | AMI BIOS – 64MB ROM |
| H/W Monitor | Supports System temperature, Voltage, and Cooling fan status monitoring |
| Watchdog Timer | 1~255 steps by software program |
| Smart Fan Control | — |
| Wake On LAN/ PXE | Yes |
| Power State | S3,S4,S5 |
| Graphics |
| Graphics Chipset | Intel® Core™i7/i5/i3 + Q67 |
| Graphics Multi Display | VGA+HDMI, VGA+DVI, HDMI+DVI |
| VGA | 1 |
| DVI | 1 |
| HDMI | 1 |
| DisplayPort | — |
| LVDS | — |
| Backlight Control | Voltage |
| Environmental & power |
| Battery | Lithium Battery |
| Power Requirement | 12V DC |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40 °F ~ 176 °F (-40 °C ~ 80 °C) |
| Operating Humidity | 0% ~ 90% R/H, non-condensing |
| Certification | CE/FCC |
| Form Factor | ATX form Factor, 12” x 9.6” (305mm x 244mm) |
| Weight | 1.76 lb (0.8 kg) |
| MTBF (hours) | 52000 |
| Rear panel I/O ports |
| USB | USB 2.0 x 4 with Type A connectors |
| Display I/O | HDMI x 1, DVI-D x 1, VGA x 1 |
| Audio I/O | Line-in, Mic-in, Line-out |
| LAN I/O | RJ-45 x 2 |
| Serial Port | RS-232 x 1 |
| PS/2 Port | Mini-Din PS/2 K/B and Mouse x 1 |
| Internal I/O connectors |
| Storage | SATA 6.0 Gb/s x 2, SATA 3.0 Gb/s x 4, Supports RAID 0,1,5,10 |
| USB | USB 2.0 x 8 |
| Display I/O | — |
| Serial Port | RS-232 x 3, RS-232/422/485 x 1 |
| Parallel Port | LPT x 1 |
| DIO | 8-bit programmable (4-in/4-out) |
| Fan | CPU Fan connector(s) (4-pin) x 1, Chassis Fan connector(s) (4-pin) x 1 |
| Power | 24-pin ATX connector x 1, 4-pin connector x 1 |
| Others | IrDA x 1 |
| OS |
| OS support | Windows® XP |
| Windows® 7 32/64-bit |
| Linux Fedora |
