| SPEC ITEM | DESCRIPTION |
| System |
| Processor | 4th Generation Intel® Core™ i7/i5/i3/Pentium®/Celeron® 22nm LGA 1150 socket Processor |
| Chipset | Intel® H81 |
| Memory | 240-pin DIMM x 2, max. 16GB, DDR3 1600/1333, Dual channel |
| I/O Chipset | F81866D, F81216HD |
| Ethernet | Realtek PCIe Gb LAN 8111G x 2 |
| Audio | Realtek® ALC887 |
| TPM | — |
| Expansion Slot | PCIe [x16] x 1, PCIe [x1] x 2 |
| BIOS | 64Mbit Flash ROM x 1, AMI BIOS |
| H/W Monitor | Temperature Monitor on CPU/System, Voltage Monitor on Vcore/5V/12V, Fan Monitor on CPU/Chassis |
| Watchdog Timer | 1~255 steps by software program |
| Smart Fan Control | CPU Fan/ Chassis Fan x 2 |
| Wake On LAN/ PXE | Yes (WOL/PXE) |
| Power State | S3, S4, S5 |
| Graphics |
| Graphics Chipset | Intel® HD Graphics |
| Graphics Multi Display | VGA+DVI-D, VGA+VGA |
| VGA | Up to 1920 x 1200 @60Hz |
| DVI | Up to 1920 x 1200 @60Hz |
| HDMI | — |
| DisplayPort | — |
| LVDS | — |
| eDP | — |
| Backlight Control | — |
| Environmental & power |
| Battery | Lithium battery |
| Power Requirement | 24-pin ATX connector x 1, 4-pin ATX 12V Power connector x 1 |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
| Operating Humidity | 0% ~ 90% RH, non-condensing |
| Certification | CE & FCC Class A |
| Form Factor | Micro-ATX, 9.6” x 9.6” (244mm x 244mm) |
| Weight | 1.76 lb (0.8 Kg) |
| MTBF (hours) | 220,420 |
| Rear panel I/O ports |
| USB | USB 3.0 x 6, USB 2.0 x 8 |
| Display I/O | DVI-I x 1, VGA x 1 |
| Audio I/O | Line-in, Mic-in, Line-out |
| LAN I/O | RJ-45 x 2 |
| Serial Port | — |
| PS/2 Port | Combo Port (Keyboard & Mouse) x 1 |
| Others | — |
| Internal I/O connectors |
| Storage | SATA 6.0Gb/s x 2, SATA 3.0Gb/s x 2 |
| USB | — |
| Display I/O | — |
| Audio I/O | AAFP x 1 |
| Serial Port | RS-232/422/485 x 1, RS-232 x 9 |
| PS/2 Port | — |
| Parallel Port | — |
| DIO | 8-bit x 1 (In/Out programmable) |
| Fan | 4-pin CPU Fan x 1, 4-pin Chassis Fan x 2 |
| Others | Front panel header x 1, Clear CMOS jumper x 1, BIOS flash header (2[x4]P p=1.27mm) x 1 |
| OS |
| OS support | Windows® 7 32/64-bit |
| Windows® 8.1 32/64-bit |
| Linux Fedora |
