Description
| SPEC ITEM | DESCRIPTION |
| Form Factor | |
| Dimensions | – Mini-ITX (6.7-in * 6.7-in, 170 * 170mm) |
| Processor System | |
| CPU | – Intel® LGA1151 Skylake/Kabylake Processor (TDP 65W) |
| Core Number | – (By CPU) |
| Max Speed | – (By CPU) |
| L2 Cache | – (By CPU) |
| Chipset | – Q170 |
| BIOS | – AMI Flash ROM |
| Expansion Slot | |
| Mini-PCIe | – 1 (full size) |
| PCIe | – 1 * PCIe x4 side-slot (4 * PCIe x1 combo signals) |
| SIM card holder | – 1 |
| Memory | |
| Technology | – Dual CH DDR4 2133MHz SDRAM |
| Max. | – 32GB |
| Socket | – 2 * SO-DIMM |
| Graphics | |
| Controller | – Intel® HD Graphics |
| VRAM | – Shared Memory |
| LVDS | – 1 (Max Resolution : 1920×1080@60Hz) |
| HDMI 1.4b | – 1 (Max Resolution : 3840×2160@30Hz) |
| DisplayPort 1.2 | – 2 (Max Resolution : 4096 x 2304@60Hz) |
| MultiDisplay | – Triple Displays |
| Ethernet | |
| Ethernet | – 10/100/1000 Mbps |
| Controller | – 2 * Intel® Gigabit LAN (i211AT * 1 & i219LM * 1) |
| Connector | – 2 * RJ 45 |
| Audio | |
| CODEC | – HD Audio : Realtek ALC662VD |
| Channel | – Line-In, Line-Out, MIC |
| SATA | |
| Max Data Transfer Rate | – 4 * SATAIII (6.0Gb/s) |
| Rear I/O | |
| HDMI | – 1 |
| DisplayPort | – 2 |
| Ethernet | – 2 |
| USB | – 4 * USB 3.0 |
| Audio | – 1 (Line-in, Line-out, MIC) |
| Serial | – 2 (COM1/2: RS232/422/485) |
| DC-input | – 1 |
| Internal Connector | |
| USB | – 2 * USB 2.0 |
| PS/2 | – 1 |
| LVDS / inverter | – 1 |
| eDP | – 0 |
| VGA | – 0 |
| Serial | – 4 |
| SATA | – 4 * SATAIII (6.0Gb/s) |
| mPCIe | – 1 (full size) |
| Parallel | – 0 |
| mSATA | – 0 |
| M.2 | – 0 |
| GPIO | – 1 (8 bit) |
| Chassis intrusion | – 1 |
| Audio Header | – 1 |
| SMBUS/ I2C | – 1 |
| AT mode | – 1 |
| TPM | – 1 (on board option) |
| Others | – Support RAID 0, 1, 5, 10 |
| Watchdog Timer | |
| Output | – From Super I/O to drag RESETCON# |
| Interval | – 256 segments (10sec ~ 255min) |
| Power Requirements | |
| Input PWR | – +9~24V DC-in |
| Power On | AT/ATX Supported |
| – AT : Directly PWR on as Power input ready | |
| – – ATX: Press Button to PWR on after Power input ready | |
| Certifications | |
| Certifications | – CE, FCC, RoHS, REACH |
| Environment | |
| Temperature | – Operating: 0°C ~ 60°C |
| – Storage: -20°C ~ 85°C | |
