Description
| SPEC ITEM | DESCRIPTION |
| Dimensions | – 185 * 48 * 142 mm |
| Construction | – Aluminum housing |
| Colors | – Black |
| System model | – JBC376C55(W)-2930G4 |
| MB model | – JNC55-E2930-4G |
| CPU | – INTEL® Bay Trail-M N2930 SoC Processor (1.86GHz) |
| BIOS | – AMI UEFI |
| Memory | – Onboard SAMSUNG 4G/1333MHz DDR3L Memory |
| Storage Space | – 1 * 2.5” SATA Device (Max Height 9.5 mm) |
| – 1 * m-SATA SSD Device (Mini PCI-E) | |
| Display Interface | – 1 * HDMI |
| – 1 * VGA | |
| Network | – 2 * RJ45 (Giga Lan) |
| – WiFi (optional / JBC376C55W-2930G4) | |
| Audio | – 1 * Line out |
| – 1 * Mic in | |
| Front I/O Port | – 5 * USB 2.0 , 1 * USB 3.0 |
| – 1 * Speaker con ( R+/R-/L+/L- ) | |
| Rear I/O Port | – 6 * COM(COM5/COM6 Support RS232/422/485) , 1 * GPIO |
| Expansion Slot | – 1 * Mini PCI-E (Full-size) |
| Power Source | – DC9～24V Jack input |
| – Adapter : AC_90~240V / DC_12V_5A / 60W | |
| Environment | – Operating Temperature : -10 ~ 60℃ |
| – Storage Temperature : -20 ~ 70 | |
| Mounting Bracket | – Wall mounting Kits |
| Packing | – Net Weight：1.4KG |
| – Gross Weight：2.7KG | |
| – Color Box Dimension：250(W) x 118 (D) x 295 (H) mm |
