RBT591-Q170 ATX Motherboard

»4th Generation Intel® Core i7 / i5 / i3 / Pentium Processor

»Long Life Embedded Class with Planned Lifecycle Through Q2’2020

»Intel HD 4000/5000 Graphics, DirectX 11.1

»Support up to Three Independent Displays, HDMI, DVI, VGA, 24bit LVDS

»Supports iAMT 9.0 Function

»ECO-design for EuP/Er

Description

SPEC ITEM	DESCRIPTION
Processor	6th / 7th Gen Intel® Core i7 / i5 / i3 / Pentium Processor
Processor	Socket LGA 1151 (Formerly Skylake and Kaby Lake)
Chipset	Intel Q170
Memory	4 x 288-pin UDIMM un-buffered Dual Channel DDR4-2133 up to 64GB Total
Graphics	Requires Intel Core processor with Intel HD Graphics
Audio	Realtek ALC662 5.1 Channel Audio
LAN	1 x Intel I219-LM PHY Gigabit LAN (iAMT 11.0)
LAN	1 x Intel I211-AT PCI-E Gigabit LAN
Storage	4 x SATA3 6Gb/s
	1 x SATA Express
	1 x M.2 slot (SATA3 + PCIe 3.0 x4, M-key, 2242/2260/2280/22110)
	RAID 0, 1, 5, 10
Super IO	FINTEK F81866A
