Description
| SPEC ITEM | DESCRIPTION |
| Part No | Rear of KVM-1701S-AST-M2-IP , Rear of KVM-1708S-AST-M2-IP , Rear of KVM-1716S-AST-M2-IP |
| Direct no. of Computers | 1, 8, 16 |
| Maximum no. of Computers | 1 , 232(Daisy Chain) , 240(Daisy chain) |
| Size | 17″ |
| Backlight | LED |
| Resolution | 1280*1024 |
| Max. color | 16.7M |
| Luminance | 250cd/m2 |
| View Angel (H/V) | 176 / 170 |
| Contrast Ratio | 1000:01:00 |
| Port Selection | Push Button, OSD or Hotkey |
| USB Local console | USB |
| KB/Mouse Emulation | USB & PS2 |
| Rack Depth | 380mm to 620mm ( rack cabinet front rails to rear rails ) |
| Power | 100-240V AC 50/60Hz via IEC Type power cord |
| Environment | Operation temp: 0 to 50℃ Storage temp: -20 to 60℃Humidity: 10% – 90%, non-condensing Shock: 10G acceleration ( 11ms duration) Vibration: 17 to 500Hz 1G PTP |
| Physical Dimensions / Net Weights | 443x42x457.2mm (WxHxD) /14KG |
| Packing Dimensions / Gross weights | 605x168x700mm (WxHxD) /17KG |
